Main Features
Excellent motor control performance
■High-performance DSP control chip, current loop real-time control cycle: 125μs
■Advanced vector control algorithm with fully decoupled control of torque and excitation current, delivering high low-frequency torque output
■High-precision torque and speed control to meet application demands of most industries
■Supports control of standard induction motors, asynchronous servo motors and synchronous servo motors
■Both open-loop and closed-loop vector control reach advanced industry standards
Strong overload capacity
■150% overload capacity for 1 minute, suitable for most heavy-load scenarios
■Independent air duct design with excellent heat dissipation ensures stable operation under heavy and overload conditions
Fully isolated control terminals design
■Comes standard with one isolated RS485 communication port (standard Modbus protocol)
■Comes standard with one incremental encoder interface
■Standard configuration: 5 DI, 4 DO, 2 AI, 2 AO, 10V reference voltage and 24V external power supply
■ Fully isolated control port design delivers strong anti-interference capability
Powerful expandability
■Supports expansion of mainstream field buses including Profinet, EtherCAT,CANbus and Modbus/TCP.
■Expansion cards for various motor encoder feedback such as resolver and absolute encoder
■Analog and digital I/O expansion
■Remote operation panel with standard RJ45 Ethernet port design
Comprehensive protection functions and high reliability
■Complete protection mechanisms against overload, overcurrent, overvoltage,ground fault, short circuit, stall and overheating.
■Fast current limiting function prevents inverter overcurrent alarms and extends fault-free operation time.
■Excellent torque response performance effectively suppresses various motor disturbances.
■150% overload test and 48-hour high-temperature aging test.
